Base class for SdFile with Print and C++ streams. More...

#include <SdBaseFile.h>

Inheritance diagram for SdBaseFile:

[legend]

Collaboration diagram for SdBaseFile:

[legend]

Public Member Functions
uint32_t	available ()
void	clearWriteError ()
bool	close ()
bool	contiguousRange (uint32_t bgnBlock, uint32_t endBlock)
bool	createContiguous (SdBaseFile dirFile, const char path, uint32_t size)
uint32_t	curCluster () const
uint32_t	curPosition () const
bool	dirEntry (dir_t *dir)
bool	exists (const char *name)
int16_t	fgets (char str, int16_t num, char delim=0)
uint32_t	fileSize () const
uint32_t	firstCluster () const
bool	getFilename (char *name)
void	getpos (FatPos_t *pos)
bool	getWriteError ()
bool	isDir () const
bool	isFile () const
bool	isOpen () const
bool	isRoot () const
bool	isSubDir () const
void	ls (Print *pr, uint8_t flags=0, uint8_t indent=0)
void	ls (uint8_t flags=0)
bool	mkdir (SdBaseFile dir, const char path, bool pFlag=true)
bool	open (SdBaseFile *dirFile, uint16_t index, uint8_t oflag)
bool	open (SdBaseFile dirFile, const char path, uint8_t oflag)
bool	open (const char *path, uint8_t oflag=O_READ)
bool	openNext (SdBaseFile *dirFile, uint8_t oflag)
bool	openRoot (SdVolume *vol)
int	peek ()
bool	printCreateDateTime (Print *pr)
int	printField (int16_t value, char term)
int	printField (uint16_t value, char term)
int	printField (int32_t value, char term)
int	printField (uint32_t value, char term)
bool	printModifyDateTime (Print *pr)
bool	printName (Print *pr)
bool	printName ()
int16_t	read ()
int	read (void *buf, size_t nbyte)
int8_t	readDir (dir_t *dir)
bool	remove ()
bool	rename (SdBaseFile dirFile, const char newPath)
void	rewind ()
bool	rmdir ()
bool	rmRfStar ()
	SdBaseFile (const char *path, uint8_t oflag)
	SdBaseFile ()
bool	seekCur (int32_t offset)
bool	seekEnd (int32_t offset=0)
bool	seekSet (uint32_t pos)
void	setpos (FatPos_t *pos)
bool	sync ()
bool	timestamp (SdBaseFile *file)
bool	timestamp (uint8_t flag, uint16_t year, uint8_t month, uint8_t day, uint8_t hour, uint8_t minute, uint8_t second)
bool	truncate (uint32_t size)
uint8_t	type () const
SdVolume *	volume () const
int	write (const void *buf, size_t nbyte)
Static Public Member Functions
static SdBaseFile *	cwd ()
static void	dateTimeCallback (void(dateTime)(uint16_t date, uint16_t *time))
static void	dateTimeCallbackCancel ()
static void	dirName (const dir_t &dir, char *name)
static void	printFatDate (uint16_t fatDate)
static void	printFatDate (Print *pr, uint16_t fatDate)
static void	printFatTime (Print *pr, uint16_t fatTime)
static void	printFatTime (uint16_t fatTime)
static bool	remove (SdBaseFile dirFile, const char path)
Public Attributes
bool	writeError
Friends
class	SdFat

Detailed Description

Base class for SdFile with Print and C++ streams.

Constructor & Destructor Documentation

SdBaseFile::SdBaseFile ( ) [inline]

Create an instance.

SdBaseFile::SdBaseFile	(	const char *	path,
		uint8_t	oflag
	)

Create a file object and open it in the current working directory.

Parameters:

[in]	path	A path with a valid 8.3 DOS name for a file to be opened.
[in]	oflag	Values for oflag are constructed by a bitwise-inclusive OR of open flags. see SdBaseFile::open(SdBaseFile, const char, uint8_t).

Member Function Documentation

uint32_t SdBaseFile::available ( ) [inline]

Returns:: number of bytes available from yhe current position to EOF

void SdBaseFile::clearWriteError ( ) [inline]

Set writeError to zero

Reimplemented in SdFile.

bool SdBaseFile::close ( )

Close a file and force cached data and directory information to be written to the storage device.

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure. Reasons for failure include no file is open or an I/O error.

Reimplemented in fstream, ifstream, and ofstream.

bool SdBaseFile::contiguousRange	(	uint32_t *	bgnBlock,
		uint32_t *	endBlock
	)

Check for contiguous file and return its raw block range.

Parameters:

[out]	bgnBlock	the first block address for the file.
[out]	endBlock	the last block address for the file.

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure. Reasons for failure include file is not contiguous, file has zero length or an I/O error occurred.

bool SdBaseFile::createContiguous	(	SdBaseFile *	dirFile,
		const char *	path,
		uint32_t	size
	)

Create and open a new contiguous file of a specified size.

Note:: This function only supports short DOS 8.3 names. See open() for more information.

Parameters:

[in]	dirFile	The directory where the file will be created.
[in]	path	A path with a valid DOS 8.3 file name.
[in]	size	The desired file size.

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure. Reasons for failure include path contains an invalid DOS 8.3 file name, the FAT volume has not been initialized, a file is already open, the file already exists, the root directory is full or an I/O error.

uint32_t SdBaseFile::curCluster ( ) const [inline]

Returns:: The current cluster number for a file or directory.

uint32_t SdBaseFile::curPosition ( ) const [inline]

Returns:: The current position for a file or directory.

static SdBaseFile* SdBaseFile::cwd ( ) [inline, static]

Returns:: Current working directory

static void SdBaseFile::dateTimeCallback ( void(*)(uint16_t *date, uint16_t *time) dateTime ) [inline, static]

Set the date/time callback function

Parameters:

[in] dateTime The user's call back function. The callback function is of the form:

 void dateTime(uint16_t* date, uint16_t* time) {
   uint16_t year;
   uint8_t month, day, hour, minute, second;

   // User gets date and time from GPS or real-time clock here

   // return date using FAT_DATE macro to format fields
   *date = FAT_DATE(year, month, day);

   // return time using FAT_TIME macro to format fields
   *time = FAT_TIME(hour, minute, second);
 }

Sets the function that is called when a file is created or when a file's directory entry is modified by sync(). All timestamps, access, creation, and modify, are set when a file is created. sync() maintains the last access date and last modify date/time.

See the timestamp() function.

static void SdBaseFile::dateTimeCallbackCancel ( ) [inline, static]

Cancel the date/time callback function.

bool SdBaseFile::dirEntry ( dir_t * dir )

Return a file's directory entry.

Parameters:

[out] dir Location for return of the file's directory entry.

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure.

void SdBaseFile::dirName	(	const dir_t &	dir,
		char *	name
	)		`[static]`

Format the name field of dir into the 13 byte array name in standard 8.3 short name format.

Parameters:

[in]	dir	The directory structure containing the name.
[out]	name	A 13 byte char array for the formatted name.

bool SdBaseFile::exists ( const char * name )

Test for the existence of a file in a directory

Parameters:

[in] name Name of the file to be tested for.

The calling instance must be an open directory file.

dirFile.exists("TOFIND.TXT") searches for "TOFIND.TXT" in the directory dirFile.

Returns:: true if the file exists else false.

int16_t SdBaseFile::fgets	(	char *	str,
		int16_t	num,
		char *	delim = `0`
	)

Get a string from a file.

fgets() reads bytes from a file into the array pointed to by str, until num - 1 bytes are read, or a delimiter is read and transferred to str, or end-of-file is encountered. The string is then terminated with a null byte.

fgets() deletes CR, '\r', from the string. This insures only a '\n' terminates the string for Windows text files which use CRLF for newline.

Parameters:

[out]	str	Pointer to the array where the string is stored.
[in]	num	Maximum number of characters to be read (including the final null byte). Usually the length of the array str is used.
[in]	delim	Optional set of delimiters. The default is "\n".

Returns:: For success fgets() returns the length of the string in str. If no data is read, fgets() returns zero for EOF or -1 if an error occurred.

uint32_t SdBaseFile::fileSize ( ) const [inline]

Returns:: The total number of bytes in a file or directory.

uint32_t SdBaseFile::firstCluster ( ) const [inline]

Returns:: The first cluster number for a file or directory.

bool SdBaseFile::getFilename ( char * name )

Get a file's name

Parameters:

[out] name An array of 13 characters for the file's name.

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure.

void SdBaseFile::getpos ( FatPos_t * pos )

get position for streams

Parameters:

[out] pos struct to receive position

bool SdBaseFile::getWriteError ( ) [inline]

Returns:: value of writeError

Reimplemented in SdFile.

bool SdBaseFile::isDir ( ) const [inline]

Returns:: True if this is a directory else false.

bool SdBaseFile::isFile ( ) const [inline]

Returns:: True if this is a normal file else false.

bool SdBaseFile::isOpen ( ) const [inline]

Returns:: True if this is an open file/directory else false.

bool SdBaseFile::isRoot ( ) const [inline]

Returns:: True if this is the root directory.

bool SdBaseFile::isSubDir ( ) const [inline]

Returns:: True if this is a subdirectory else false.

void SdBaseFile::ls	(	Print *	pr,
		uint8_t	flags = `0`,
		uint8_t	indent = `0`
	)

List directory contents.

Parameters:

[in]	pr	Print stream for list.
[in]	flags	The inclusive OR of

LS_DATE - Print file modification date

LS_SIZE - Print file size.

LS_R - Recursive list of subdirectories.

Parameters:

[in] indent Amount of space before file name. Used for recursive list to indicate subdirectory level.

void SdBaseFile::ls ( uint8_t flags = 0 )

List directory contents to stdOut.

Parameters:

[in] flags The inclusive OR of

LS_DATE - Print file modification date

LS_SIZE - Print file size.

LS_R - Recursive list of subdirectories.

bool SdBaseFile::mkdir	(	SdBaseFile *	parent,
		const char *	path,
		bool	pFlag = `true`
	)

Make a new directory.

Parameters:

[in]	parent	An open SdFat instance for the directory that will contain the new directory.
[in]	path	A path with a valid 8.3 DOS name for the new directory.
[in]	pFlag	Create missing parent directories if true.

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure. Reasons for failure include this file is already open, parent is not a directory, path is invalid or already exists in parent.

bool SdBaseFile::open	(	SdBaseFile *	dirFile,
		uint16_t	index,
		uint8_t	oflag
	)

Open a file by index.

Parameters:

[in]	dirFile	An open SdFat instance for the directory.
[in]	index	The index of the directory entry for the file to be opened. The value for index is (directory file position)/32.
[in]	oflag	Values for oflag are constructed by a bitwise-inclusive OR of flags O_READ, O_WRITE, O_TRUNC, and O_SYNC.

See open() by path for definition of flags.

Returns:: true for success or false for failure.

bool SdBaseFile::open	(	SdBaseFile *	dirFile,
		const char *	path,
		uint8_t	oflag
	)

Open a file or directory by name.

Parameters:

[in]	dirFile	An open SdFat instance for the directory containing the file to be opened.
[in]	path	A path with a valid 8.3 DOS name for a file to be opened.
[in]	oflag	Values for oflag are constructed by a bitwise-inclusive OR of flags from the following list

O_READ - Open for reading.

O_RDONLY - Same as O_READ.

O_WRITE - Open for writing.

O_WRONLY - Same as O_WRITE.

O_RDWR - Open for reading and writing.

O_APPEND - If set, the file offset shall be set to the end of the file prior to each write.

O_AT_END - Set the initial position at the end of the file.

O_CREAT - If the file exists, this flag has no effect except as noted under O_EXCL below. Otherwise, the file shall be created

O_EXCL - If O_CREAT and O_EXCL are set, open() shall fail if the file exists.

O_SYNC - Call sync() after each write. This flag should not be used with write(uint8_t), write_P(PGM_P), writeln_P(PGM_P), or the Arduino Print class. These functions do character at a time writes so sync() will be called after each byte.

O_TRUNC - If the file exists and is a regular file, and the file is successfully opened and is not read only, its length shall be truncated to 0.

WARNING: A given file must not be opened by more than one SdBaseFile object of file corruption may occur.

Note:: Directory files must be opened read only. Write and truncation is not allowed for directory files.

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure. Reasons for failure include this file is already open, dirFile is not a directory, path is invalid, the file does not exist or can't be opened in the access mode specified by oflag.

bool SdBaseFile::open	(	const char *	path,
		uint8_t	oflag = `O_READ`
	)

Open a file in the current working directory.

Parameters:

[in]	path	A path with a valid 8.3 DOS name for a file to be opened.
[in]	oflag	Values for oflag are constructed by a bitwise-inclusive OR of open flags. see SdBaseFile::open(SdBaseFile, const char, uint8_t).

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure.

Reimplemented in fstream, ifstream, and ofstream.

bool SdBaseFile::openNext	(	SdBaseFile *	dirFile,
		uint8_t	oflag
	)

Open the next file or subdirectory in a directory.

Parameters:

[in]	dirFile	An open SdFat instance for the directory containing the file to be opened.
[in]	oflag	Values for oflag are constructed by a bitwise-inclusive OR of flags O_READ, O_WRITE, O_TRUNC, and O_SYNC.

See open() by path for definition of flags.

Returns:: true for success or false for failure.

bool SdBaseFile::openRoot ( SdVolume * vol )

Open a volume's root directory.

Parameters:

[in] vol The FAT volume containing the root directory to be opened.

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure. Reasons for failure include the file is already open, the FAT volume has not been initialized or it a FAT12 volume.

int SdBaseFile::peek ( )

Return the next available byte without consuming it.

Returns:: The byte if no error and not at eof else -1;

bool SdBaseFile::printCreateDateTime ( Print * pr )

Print a file's creation date and time

Parameters:

[in] pr Print stream for output.

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure.

void SdBaseFile::printFatDate ( uint16_t fatDate ) [static]

Print a directory date field to stdOut.

Format is yyyy-mm-dd.

Parameters:

[in] fatDate The date field from a directory entry.

void SdBaseFile::printFatDate	(	Print *	pr,
		uint16_t	fatDate
	)		`[static]`

Print a directory date field.

Format is yyyy-mm-dd.

Parameters:

[in]	pr	Print stream for output.
[in]	fatDate	The date field from a directory entry.

void SdBaseFile::printFatTime ( uint16_t fatTime ) [static]

Print a directory time field to stdOut.

Format is hh:mm:ss.

Parameters:

[in] fatTime The time field from a directory entry.

void SdBaseFile::printFatTime	(	Print *	pr,
		uint16_t	fatTime
	)		`[static]`

Print a directory time field.

Format is hh:mm:ss.

Parameters:

[in]	pr	Print stream for output.
[in]	fatTime	The time field from a directory entry.

int SdBaseFile::printField	(	int16_t	value,
		char	term
	)

Print a number followed by a field terminator.

Parameters:

[in]	value	The number to be printed.
[in]	term	The field terminator. Use '\n' for CR LF.

Returns:: The number of bytes written or -1 if an error occurs.

int SdBaseFile::printField	(	uint16_t	value,
		char	term
	)

Print a number followed by a field terminator.

Parameters:

[in]	value	The number to be printed.
[in]	term	The field terminator. Use '\n' for CR LF.

Returns:: The number of bytes written or -1 if an error occurs.

int SdBaseFile::printField	(	int32_t	value,
		char	term
	)

Print a number followed by a field terminator.

Parameters:

[in]	value	The number to be printed.
[in]	term	The field terminator. Use '\n' for CR LF.

Returns:: The number of bytes written or -1 if an error occurs.

int SdBaseFile::printField	(	uint32_t	value,
		char	term
	)

Print a number followed by a field terminator.

Parameters:

[in]	value	The number to be printed.
[in]	term	The field terminator. Use '\n' for CR LF.

Returns:: The number of bytes written or -1 if an error occurs.

bool SdBaseFile::printModifyDateTime ( Print * pr )

Print a file's modify date and time

Parameters:

[in] pr Print stream for output.

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure.

bool SdBaseFile::printName ( )

Print a file's name to stdOut

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure.

bool SdBaseFile::printName ( Print * pr )

Print a file's name

Parameters:

[in] pr Print stream for output.

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure.

int16_t SdBaseFile::read ( )

Read the next byte from a file.

Returns:: For success read returns the next byte in the file as an int. If an error occurs or end of file is reached -1 is returned.

int SdBaseFile::read	(	void *	buf,
		size_t	nbyte
	)

Read data from a file starting at the current position.

Parameters:

[out]	buf	Pointer to the location that will receive the data.
[in]	nbyte	Maximum number of bytes to read.

Returns:: For success read() returns the number of bytes read. A value less than nbyte, including zero, will be returned if end of file is reached. If an error occurs, read() returns -1. Possible errors include read() called before a file has been opened, corrupt file system or an I/O error occurred.

int8_t SdBaseFile::readDir ( dir_t * dir )

Read the next directory entry from a directory file.

Parameters:

[out] dir The dir_t struct that will receive the data.

Returns:: For success readDir() returns the number of bytes read. A value of zero will be returned if end of file is reached. If an error occurs, readDir() returns -1. Possible errors include readDir() called before a directory has been opened, this is not a directory file or an I/O error occurred.

bool SdBaseFile::remove	(	SdBaseFile *	dirFile,
		const char *	path
	)		`[static]`

Remove a file.

The directory entry and all data for the file are deleted.

Parameters:

[in]	dirFile	The directory that contains the file.
[in]	path	Path for the file to be removed.

Note:: This function should not be used to delete the 8.3 version of a file that has a long name. For example if a file has the long name "New Text Document.txt" you should not delete the 8.3 name "NEWTEX~1.TXT".

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure. Reasons for failure include the file is a directory, is read only, dirFile is not a directory, path is not found or an I/O error occurred.

bool SdBaseFile::remove ( )

Remove a file.

The directory entry and all data for the file are deleted.

Note:: This function should not be used to delete the 8.3 version of a file that has a long name. For example if a file has the long name "New Text Document.txt" you should not delete the 8.3 name "NEWTEX~1.TXT".

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure. Reasons for failure include the file read-only, is a directory, or an I/O error occurred.

bool SdBaseFile::rename	(	SdBaseFile *	dirFile,
		const char *	newPath
	)

Rename a file or subdirectory.

Parameters:

[in]	dirFile	Directory for the new path.
[in]	newPath	New path name for the file/directory.

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure. Reasons for failure include dirFile is not open or is not a directory file, newPath is invalid or already exists, or an I/O error occurs.

void SdBaseFile::rewind ( ) [inline]

Set the file's current position to zero.

bool SdBaseFile::rmdir ( )

Remove a directory file.

The directory file will be removed only if it is empty and is not the root directory. rmdir() follows DOS and Windows and ignores the read-only attribute for the directory.

Note:: This function should not be used to delete the 8.3 version of a directory that has a long name. For example if a directory has the long name "New folder" you should not delete the 8.3 name "NEWFOL~1".

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure. Reasons for failure include the file is not a directory, is the root directory, is not empty, or an I/O error occurred.

bool SdBaseFile::rmRfStar ( )

Recursively delete a directory and all contained files.

This is like the Unix/Linux 'rm -rf *' if called with the root directory hence the name.

Warning - This will remove all contents of the directory including subdirectories. The directory will then be removed if it is not root. The read-only attribute for files will be ignored.

Note:: This function should not be used to delete the 8.3 version of a directory that has a long name. See remove() and rmdir().

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure.

bool SdBaseFile::seekCur ( int32_t offset ) [inline]

Set the files position to current position + pos. See seekSet().

Parameters:

[in] offset The new position in bytes from the current position.

Returns:: true for success or false for failure.

bool SdBaseFile::seekEnd ( int32_t offset = 0 ) [inline]

Set the files position to end-of-file + offset. See seekSet().

Parameters:

[in] offset The new position in bytes from end-of-file.

Returns:: true for success or false for failure.

bool SdBaseFile::seekSet ( uint32_t pos )

Sets a file's position.

Parameters:

[in] pos The new position in bytes from the beginning of the file.

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure.

void SdBaseFile::setpos ( FatPos_t * pos )

set position for streams

Parameters:

[out] pos struct with value for new position

bool SdBaseFile::sync ( )

The sync() call causes all modified data and directory fields to be written to the storage device.

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure. Reasons for failure include a call to sync() before a file has been opened or an I/O error.

bool SdBaseFile::timestamp ( SdBaseFile * file )

Copy a file's timestamps

Parameters:

[in] file File to copy timestamps from.

Note:: Modify and access timestamps may be overwritten if a date time callback function has been set by dateTimeCallback().

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure.

bool SdBaseFile::timestamp	(	uint8_t	flags,
		uint16_t	year,
		uint8_t	month,
		uint8_t	day,
		uint8_t	hour,
		uint8_t	minute,
		uint8_t	second
	)

Set a file's timestamps in its directory entry.

Parameters:

[in] flags Values for flags are constructed by a bitwise-inclusive OR of flags from the following list

T_ACCESS - Set the file's last access date.

T_CREATE - Set the file's creation date and time.

T_WRITE - Set the file's last write/modification date and time.

Parameters:

[in]	year	Valid range 1980 - 2107 inclusive.
[in]	month	Valid range 1 - 12 inclusive.
[in]	day	Valid range 1 - 31 inclusive.
[in]	hour	Valid range 0 - 23 inclusive.
[in]	minute	Valid range 0 - 59 inclusive.
[in]	second	Valid range 0 - 59 inclusive

Note:: It is possible to set an invalid date since there is no check for the number of days in a month.; Modify and access timestamps may be overwritten if a date time callback function has been set by dateTimeCallback().

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure.

bool SdBaseFile::truncate ( uint32_t length )

Truncate a file to a specified length. The current file position will be maintained if it is less than or equal to length otherwise it will be set to end of file.

Parameters:

[in] length The desired length for the file.

Returns:: The value one, true, is returned for success and the value zero, false, is returned for failure. Reasons for failure include file is read only, file is a directory, length is greater than the current file size or an I/O error occurs.

uint8_t SdBaseFile::type ( ) const [inline]

Type of file. You should use isFile() or isDir() instead of type() if possible.

Returns:: The file or directory type.

SdVolume* SdBaseFile::volume ( ) const [inline]

Returns:: SdVolume that contains this file.

int SdBaseFile::write	(	const void *	buf,
		size_t	nbyte
	)

Write data to an open file.

Note:: Data is moved to the cache but may not be written to the storage device until sync() is called.

Parameters:

[in]	buf	Pointer to the location of the data to be written.
[in]	nbyte	Number of bytes to write.

Returns:: For success write() returns the number of bytes written, always nbyte. If an error occurs, write() returns -1. Possible errors include write() is called before a file has been opened, write is called for a read-only file, device is full, a corrupt file system or an I/O error.

Reimplemented in SdFile.

Member Data Documentation

bool SdBaseFile::writeError

writeError is set to true if an error occurs during a write(). Set writeError to false before calling print() and/or write() and check for true after calls to print() and/or write().

The documentation for this class was generated from the following files:

Arduino/libraries/SdFat/SdBaseFile.h
Arduino/libraries/SdFat/SdBaseFile.cpp

Public Member Functions

Static Public Member Functions

Public Attributes

Friends

Detailed Description

Constructor & Destructor Documentation

Member Function Documentation

Member Data Documentation
