ArduinoInStream Class Reference

Input stream for Arduino Stream objects. More...

#include <ArduinoStream.h>

Inheritance diagram for ArduinoInStream:

Collaboration diagram for ArduinoInStream:

List of all members.

Public Types
typedef unsigned int	fmtflags
typedef unsigned char	iostate
typedef int32_t	off_type
typedef uint8_t	openmode
typedef uint32_t	pos_type
enum	seekdir { beg, cur, end }
typedef uint32_t	streamsize
Public Member Functions
	ArduinoInStream (Stream &hws, char *buf, size_t size)
bool	bad () const
void	clear (iostate state=goodbit)
bool	eof () const
bool	fail () const
char	fill ()
char	fill (char c)
fmtflags	flags () const
fmtflags	flags (fmtflags fl)
streamsize	gcount () const
int	get ()
istream &	get (char &ch)
istream &	get (char *str, streamsize n, char delim= '\n')
istream &	getline (char *str, streamsize count, char delim= '\n')
bool	good () const
istream &	ignore (streamsize n=1, int delim=-1)
void	init (const char *str)
	operator const void * () const
bool	operator! () const
istream &	operator>> (char &ch)
istream &	operator>> (unsigned int &arg)
istream &	operator>> (int &arg)
istream &	operator>> (signed char *str)
istream &	operator>> (long &arg)
istream &	operator>> (unsigned long &arg)
istream &	operator>> (istream &(*pf)(istream &str))
istream &	operator>> (double &arg)
istream &	operator>> (signed char &ch)
istream &	operator>> (float &arg)
istream &	operator>> (void *&arg)
istream &	operator>> (ios_base &(*pf)(ios_base &str))
istream &	operator>> (unsigned char *str)
istream &	operator>> (unsigned char &ch)
istream &	operator>> (ios &(*pf)(ios &str))
istream &	operator>> (bool &arg)
istream &	operator>> (char *str)
istream &	operator>> (short &arg)
istream &	operator>> (unsigned short &arg)
int	peek ()
int	precision (unsigned int n)
int	precision () const
iostate	rdstate () const
void	readline ()
istream &	seekg (off_type off, seekdir way)
istream &	seekg (pos_type pos)
fmtflags	setf (fmtflags fl, fmtflags mask)
fmtflags	setf (fmtflags fl)
void	setstate (iostate state)
void	skipWhite ()
pos_type	tellg ()
void	unsetf (fmtflags fl)
unsigned	width ()
unsigned	width (unsigned n)
Static Public Attributes
static const fmtflags	adjustfield = left | right | internal
static const openmode	app = 0X4
static const openmode	ate = 0X8
static const iostate	badbit = 0X01
static const fmtflags	basefield = dec | hex | oct
static const openmode	binary = 0X10
static const fmtflags	boolalpha = 0x0100
static const fmtflags	dec = 0x0008
static const iostate	eofbit = 0x02
static const iostate	failbit = 0X04
static const iostate	goodbit = 0x00
static const fmtflags	hex = 0x0010
static const openmode	in = 0X20
static const fmtflags	internal = 0x0004
static const fmtflags	left = 0x0001
static const fmtflags	oct = 0x0020
static const openmode	out = 0X40
static const fmtflags	right = 0x0002
static const fmtflags	showbase = 0x0200
static const fmtflags	showpoint = 0x0400
static const fmtflags	showpos = 0x0800
static const fmtflags	skipws = 0x1000
static const openmode	trunc = 0X80
static const fmtflags	uppercase = 0x4000
Protected Member Functions
uint8_t	flagsToBase ()
bool	seekoff (off_type off, seekdir way)
bool	seekpos (pos_type pos)

---

Detailed Description

Input stream for Arduino Stream objects.

---

Member Typedef Documentation

typedef unsigned int ios_base::fmtflags [inherited]

type for format flags

typedef unsigned char ios_base::iostate [inherited]

typedef for iostate bitmask

typedef int32_t ios_base::off_type [inherited]

type for relative seek offset

typedef uint8_t ios_base::openmode [inherited]

typedef for iostream open mode

typedef uint32_t ios_base::pos_type [inherited]

type for absolute seek position

typedef uint32_t ios_base::streamsize [inherited]

unsigned size that can represent maximum file size. (violates spec - should be signed)

---

Member Enumeration Documentation

enum ios_base::seekdir [inherited]

enumerated type for the direction of relative seeks

Enumerator:

beg	seek relative to the beginning of the stream
cur	seek relative to the current stream position
end	seek relative to the end of the stream

---

Constructor & Destructor Documentation

ArduinoInStream::ArduinoInStream	(	Stream &	hws,
		char *	buf,
		size_t	size
	)		[inline]

Constructor

Parameters:

[in]	hws	hardware stream
[in]	buf	buffer for input line
[in]	size	size of input buffer

---

Member Function Documentation

bool ios::bad

(

)

const [inline, inherited]

Returns:

true if bad bit is set else false.

void ios::clear

(

iostate

state = goodbit

)

[inline, inherited]

Clear iostate bits.

Parameters:

[in]

state

The flags you want to set after clearing all flags.

Reimplemented in fstream, and ofstream.

bool ios::eof

(

)

const [inline, inherited]

Returns:

true if end of file has been reached else false.

Warning: An empty file returns false before the first read.

Moral: eof() is only useful in combination with fail(), to find out whether EOF was the cause for failure

bool ios::fail

(

)

const [inline, inherited]

Returns:

true if any iostate bit other than eof are set else false.

char ios_base::fill

(

)

[inline, inherited]

Returns:

fill character

char ios_base::fill

(

char

c

)

[inline, inherited]

Set fill character

Parameters:

[in]

c

new fill character

Returns:

old fill character

fmtflags ios_base::flags

(

)

const [inline, inherited]

Returns:

format flags

fmtflags ios_base::flags

(

fmtflags

fl

)

[inline, inherited]

set format flags

Parameters:

[in]

fl

new flag

Returns:

old flags

uint8_t ios_base::flagsToBase

(

)

[inline, protected, inherited]

Returns:

current number base

streamsize istream::gcount

(

)

const [inline, inherited]

Returns:

The number of characters extracted by the last unformatted input function.

int istream::get

(

)

[inherited]

Extract a character if one is available.

Returns:

The character or -1 if a failure occurs. A failure is indicated by the stream state.

istream & istream::get

(

char &

c

)

[inherited]

Extract a character if one is available.

Parameters:

[out]

c

location to receive the extracted character.

Returns:

always returns *this. A failure is indicated by the stream state.

istream & istream::get	(	char *	str,
		streamsize	n,
		char	delim = '\n'
	)		[inherited]

Extract characters.

Parameters:

[out]	str	Location to receive extracted characters.
[in]	n	Size of str.
[in]	delim	Delimiter

Characters are extracted until extraction fails, n is less than 1, n-1 characters are extracted, or the next character equals delim (delim is not extracted). If no characters are extracted failbit is set. If end-of-file occurs the eofbit is set.

Returns:

always returns *this. A failure is indicated by the stream state.

istream & istream::getline	(	char *	str,
		streamsize	n,
		char	delim = '\n'
	)		[inherited]

Extract characters

Parameters:

[out]	str	Location to receive extracted characters.
[in]	n	Size of str.
[in]	delim	Delimiter

Characters are extracted until extraction fails, the next character equals delim (delim is extracted), or n-1 characters are extracted.

The failbit is set if no characters are extracted or n-1 characters are extracted. If end-of-file occurs the eofbit is set.

Returns:

always returns *this. A failure is indicated by the stream state.

bool ios::good

(

)

const [inline, inherited]

Returns:

True if no iostate flags are set else false.

istream & istream::ignore	(	streamsize	n = 1,
		int	delim = -1
	)		[inherited]

Extract characters and discard them.

Parameters:

[in]	n	maximum number of characters to ignore.
[in]	delim	Delimiter.

Characters are extracted until extraction fails, n characters are extracted, or the next input character equals delim (the delimiter is extracted). If end-of-file occurs the eofbit is set.

Failures are indicated by the state of the stream.

Returns:

*this

void ibufstream::init

(

const char *

str

)

[inline, inherited]

Initialize an ibufstream

Parameters:

[in]

str

pointer to string to be parsed Warning: The string will not be copied so must stay in scope.

ios::operator const void *

(

)

const [inline, inherited]

Returns:

null pointer if fail() is true.

bool ios::operator!

(

)

const [inline, inherited]

Returns:

true if fail() else false.

istream& istream::operator>>

(

istream &(*)(istream &str)

pf

)

[inline, inherited]

call manipulator

Parameters:

[in]

pf

function to call

Returns:

the stream

istream& istream::operator>>

(

char *

str

)

[inline, inherited]

Extract a character string

Parameters:

[out]

str

location to store the string.

Returns:

Is always *this. Failure is indicated by the state of *this.

istream& istream::operator>>

(

unsigned short &

arg

)

[inline, inherited]

Extract a value of type unsigned short.

Parameters:

[out]

arg

location to store the value.

Returns:

Is always *this. Failure is indicated by the state of *this.

istream& istream::operator>>

(

int &

arg

)

[inline, inherited]

Extract a value of type int.

Parameters:

[out]

arg

location to store the value.

Returns:

Is always *this. Failure is indicated by the state of *this.

istream& istream::operator>>

(

char &

ch

)

[inline, inherited]

Extract a character

Parameters:

[out]

ch

location to store the character.

Returns:

Is always *this. Failure is indicated by the state of *this.

istream& istream::operator>>

(

unsigned int &

arg

)

[inline, inherited]

Extract a value of type unsigned int.

Parameters:

[out]

arg

location to store the value.

Returns:

Is always *this. Failure is indicated by the state of *this.

istream& istream::operator>>

(

long &

arg

)

[inline, inherited]

Extract a value of type long.

Parameters:

[out]

arg

location to store the value.

Returns:

Is always *this. Failure is indicated by the state of *this.

istream& istream::operator>>

(

signed char *

str

)

[inline, inherited]

Extract a character string

Parameters:

[out]

str

location to store the string.

Returns:

Is always *this. Failure is indicated by the state of *this.

istream& istream::operator>>

(

unsigned long &

arg

)

[inline, inherited]

Extract a value of type unsigned long.

Parameters:

[out]

arg

location to store the value.

Returns:

Is always *this. Failure is indicated by the state of *this.

istream& istream::operator>>

(

double &

arg

)

[inline, inherited]

Extract a value of type double.

Parameters:

[out]

arg

location to store the value.

Returns:

Is always *this. Failure is indicated by the state of *this.

istream& istream::operator>>

(

float &

arg

)

[inline, inherited]

Extract a value of type float.

Parameters:

[out]

arg

location to store the value.

Returns:

Is always *this. Failure is indicated by the state of *this.

istream& istream::operator>>

(

signed char &

ch

)

[inline, inherited]

Extract a character

Parameters:

[out]

ch

location to store the character.

Returns:

Is always *this. Failure is indicated by the state of *this.

istream& istream::operator>>

(

void *&

arg

)

[inline, inherited]

Extract a value of type void*.

Parameters:

[out]

arg

location to store the value.

Returns:

Is always *this. Failure is indicated by the state of *this.

istream& istream::operator>>

(

ios_base &(*)(ios_base &str)

pf

)

[inline, inherited]

call manipulator

Parameters:

[in]

pf

function to call

Returns:

the stream

istream& istream::operator>>

(

unsigned char *

str

)

[inline, inherited]

Extract a character string

Parameters:

[out]

str

location to store the string.

Returns:

Is always *this. Failure is indicated by the state of *this.

istream& istream::operator>>

(

unsigned char &

ch

)

[inline, inherited]

Extract a character

Parameters:

[out]

ch

location to store the character.

Returns:

Is always *this. Failure is indicated by the state of *this.

istream& istream::operator>>

(

bool &

arg

)

[inline, inherited]

Extract a value of type bool.

Parameters:

[out]

arg

location to store the value.

Returns:

Is always *this. Failure is indicated by the state of *this.

istream& istream::operator>>

(

ios &(*)(ios &str)

pf

)

[inline, inherited]

call manipulator

Parameters:

[in]

pf

function to call

Returns:

the stream

istream& istream::operator>>

(

short &

arg

)

[inline, inherited]

Extract a value of type short.

Parameters:

[out]

arg

location to store the value.

Returns:

Is always *this. Failure is indicated by the state of *this.

int istream::peek

(

)

[inherited]

Return the next available character without consuming it.

Returns:

The character if the stream state is good else -1;

int ios_base::precision

(

unsigned int

n

)

[inline, inherited]

set precision

Parameters:

[in]

n

new precision

Returns:

old precision

int ios_base::precision

(

)

const [inline, inherited]

Returns:

precision

iostate ios::rdstate

(

)

const [inline, inherited]

Returns:

The iostate flags for this file.

void ArduinoInStream::readline

(

)

[inline]

read a line.

istream& istream::seekg

(

pos_type

pos

)

[inline, inherited]

Set the stream position

Parameters:

[in]

pos

The absolute position in which to move the read pointer.

Returns:

Is always *this. Failure is indicated by the state of *this.

istream& istream::seekg	(	off_type	off,
		seekdir	way
	)		[inline, inherited]

Set the stream position.

Parameters:

[in]	off	An offset to move the read pointer relative to way. off is a signed 32-bit int so the offset is limited to +- 2GB.
[in]	way	One of ios::beg, ios::cur, or ios::end.

Returns:

Is always *this. Failure is indicated by the state of *this.

bool ArduinoInStream::seekoff	(	off_type	off,
		seekdir	way
	)		[inline, protected]

Internal - do not use.

Parameters:

[in]	off
[in]	way

Returns:

true/false.

bool ArduinoInStream::seekpos

(

pos_type

pos

)

[inline, protected]

Internal - do not use.

Parameters:

[in]

pos

Returns:

true/false.

fmtflags ios_base::setf	(	fmtflags	fl,
		fmtflags	mask
	)		[inline, inherited]

modify format flags

Parameters:

[in]	mask	flags to be removed
[in]	fl	flags to be set after mask bits have been cleared

Returns:

old flags

fmtflags ios_base::setf

(

fmtflags

fl

)

[inline, inherited]

set format flags

Parameters:

[in]

fl

new flags to be or'ed in

Returns:

old flags

void ios::setstate

(

iostate

state

)

[inline, inherited]

Set iostate bits.

Parameters:

[in]

state

Bitts to set.

void istream::skipWhite

(

)

[inherited]

used to implement ws()

pos_type istream::tellg

(

)

[inline, inherited]

Returns:

the stream position

void ios_base::unsetf

(

fmtflags

fl

)

[inline, inherited]

clear format flags

Parameters:

[in]

fl

flags to be cleared

Returns:

old flags

unsigned ios_base::width

(

)

[inline, inherited]

Returns:

width

unsigned ios_base::width

(

unsigned

n

)

[inline, inherited]

set width

Parameters:

[in]

n

new width

Returns:

old width

---

Member Data Documentation

const fmtflags ios_base::adjustfield = left | right | internal [static, inherited]

mask for adjustfield

const openmode ios_base::app = 0X4 [static, inherited]

seek to end before each write

const openmode ios_base::ate = 0X8 [static, inherited]

open and seek to end immediately after opening

const iostate ios_base::badbit = 0X01 [static, inherited]

iostate bad bit for a nonrecoverable error.

const fmtflags ios_base::basefield = dec | hex | oct [static, inherited]

mask for basefield

const openmode ios_base::binary = 0X10 [static, inherited]

perform input and output in binary mode (as opposed to text mode)

const fmtflags ios_base::boolalpha = 0x0100 [static, inherited]

use strings true/false for bool

const fmtflags ios_base::dec = 0x0008 [static, inherited]

base 10 flag

const iostate ios_base::eofbit = 0x02 [static, inherited]

iostate bit for end of file reached

const iostate ios_base::failbit = 0X04 [static, inherited]

iostate fail bit for nonfatal error

const iostate ios_base::goodbit = 0x00 [static, inherited]

iostate for no flags

const fmtflags ios_base::hex = 0x0010 [static, inherited]

base 16 flag

const openmode ios_base::in = 0X20 [static, inherited]

open for input

const fmtflags ios_base::internal = 0x0004 [static, inherited]

fill between sign/base prefix and number

const fmtflags ios_base::left = 0x0001 [static, inherited]

left adjust fields

const fmtflags ios_base::oct = 0x0020 [static, inherited]

base 8 flag

const openmode ios_base::out = 0X40 [static, inherited]

open for output

const fmtflags ios_base::right = 0x0002 [static, inherited]

right adjust fields

const fmtflags ios_base::showbase = 0x0200 [static, inherited]

use prefix 0X for hex and 0 for oct

const fmtflags ios_base::showpoint = 0x0400 [static, inherited]

always show '.' for floating numbers

const fmtflags ios_base::showpos = 0x0800 [static, inherited]

show + sign for nonnegative numbers

const fmtflags ios_base::skipws = 0x1000 [static, inherited]

skip initial white space

const openmode ios_base::trunc = 0X80 [static, inherited]

truncate an existing stream when opening

const fmtflags ios_base::uppercase = 0x4000 [static, inherited]

use uppercase letters in number representations

---

The documentation for this class was generated from the following file:

• Arduino/libraries/SdFat/ArduinoStream.h
